Thermal Overload Protector
Created with Pixso. HCET Bimetallic Thermal Overload Protector 10A-40A Motor For Motors Compressors
Name
  • Name
  • Name
  • Name

HCET Bimetallic Thermal Overload Protector 10A-40A Motor For Motors Compressors

Brand Name: HCET
Model Number: HC01/6AP
MOQ: 1000
Price: please contact us
Delivery Time: 5-7 work days
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ROHS
Document:
6AP.pdf
Product Name:
HCET Bimetal Thermal Overload Protector
Material:
Metal/PBT Case
Temperature Range:
30~180℃
Tolerance:
±8℃,±5℃
Voltage:
30V DC / 250V AC
Current:
Customizable
Application:
Motors/Compressors
Packaging Details:
20000 pcs per carton
Supply Ability:
10000000 pcs per month
Highlight:

HCET Thermal Overload Protector

,

Compressors Thermal Overload Protector

,

HCET bimetal temperature switch

Product Description
HCET Bimetallic Thermal Overload Protector 10A-40A Motor For Motors Compressors
Product Specifications
Attribute Value
Product name HCET Bimetal Thermal Overload Protector
Material Metal/PBT case
Temperature range 30~180℃
Tolerance ±8℃,±5℃
Voltage 30V DC / 250V AC
Current Customizable
Application Motors/Compressors
Product Description

HCET series customizable overload protector utilizes a precision-calibrated bimetallic strip that bends under abnormal current-induced heat. When temperatures exceed the preset threshold (e.g., motor overload or compressor failure), the strip triggers an instant mechanical cutoff (4-10s response) to prevent equipment damage. After cooling, the device auto-resets without manual intervention, ensuring continuous protection.

Key Features
  • Industrial Machinery: Safeguards motors (0.5-30kW), CNC machines, and pumps from burnout.
  • HVAC Systems: Protects compressors in commercial cooling units and heat pumps.
  • Renewable Energy: Stabilizes solar inverters and EV charging stations under voltage surges.
  • Harsh Environments: Operates in -30°C to 200°C for oil rigs, chemical plants, and marine equipment.
Electrical Characteristics
30℃~180℃
Operating temperature range, Customizable temperature
4S~10S
Special action time can be customized
± 5°C, ±8℃
Temperature Tolerance
1A~45A
The overload current tripping range can be customized according to customer's requirements
45amps/15 volts DC 15amps/30 volts DC
25amps/250 volts AC 30amps/125 volts AC
Dimensions
HCET Bimetallic Thermal Overload Protector 10A-40A Motor For Motors Compressors 0 HCET Bimetallic Thermal Overload Protector 10A-40A Motor For Motors Compressors 1
Product Details
HCET Bimetallic Thermal Overload Protector 10A-40A Motor For Motors Compressors 2 HCET Bimetallic Thermal Overload Protector 10A-40A Motor For Motors Compressors 3
Applications
HCET Bimetallic Thermal Overload Protector 10A-40A Motor For Motors Compressors 4
