250V 16A KSD301 Thermal Switch Thermostat 120C 85C Temperature Control High Precision

250V 16A KSD301 Thermal Switch Thermostat 120C 85C Temperature Control High Precision

Brand Name:	HCET
Model Number:	KSD301/HC301
MOQ:	1000
Price:	please contact us
Delivery Time:	5-7 work days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

UL, TUV, CE

Document:

HC301.pdf

Product Name:

KSD301 Bimetal Thermal Switch

Material:

Ceramic Or Bakelite Body

Temperature Range:

-10~280℃

Tolerance:

±3℃,±5℃

Voltage:

125V/250V AC

Current:

10A/16A

Application:

Air Conditioner

Packaging Details:

2000 pcs per carton

Supply Ability:

10000000 pcs per month

Highlight:

KSD301 Thermal Switch 120C

High Precision KSD301 Thermal Switch

ksd301 250v 16a 85 c

Product Description

250V 16A KSD301 Thermal Switch Thermostat 120C 85C Temperature Control High Precision

Product Specifications

Attribute	Value
Product name	KSD301 Bimetal Thermal Switch
Material	Ceramic or Bakelite body
Temperature range	-10~280℃
Tolerance	±3℃,±5℃
Voltage	125V/250V AC
Current	10A/16A
Application	Air Conditioner

Product Description

HCET KSD301 Bimetal Thermal Switch Thermostat High Precision 120C Temperature Control Switch for Air Conditioner

The HCET KSD301 Bimetal Thermostat is a precision-engineered thermal protection device utilizing a bimetal mechanism that automatically opens/closes circuits in response to temperature changes. Designed for demanding applications, it supports dual voltage (125V and 250V) and high current capacity (10A/16A) to ensure reliable performance in HVAC systems, electric water heaters, coffee machines and industrial machinery.

With a wide temperature range (-20°C to 280°C) and UL, TUV, CE, and RoHS approvals, this thermostat ensures compliance with international safety standards and provides over-temperature protection in a compact, snap-action design.

Product Features

High current and dual voltage - Handles 10A/16A (125VAC/250VAC), ideal for heavy duty appliances and industrial equipment.
Worldwide Approvals - UL, TUV, CE and RoHS certified to meet safety and environmental requirements for EU/US/Asia markets.
Precise temperature control - Bimetal snap action mechanism can be customized with ±3°C accuracy with customizable temperature settings.
Durability in extreme environments - Reliable operation in environments ranging from -20°C to 280°C. Resistant to moisture, dust and vibration.
Multi-Industry Applications - Ideal for HVAC compressors, electric motors, medical equipment, and small household appliances requiring overheat protection.

Electrical Characteristics

Temperature range: -10℃~300℃

Temperature tolerance: ±3℃, ±5℃

Electrical specifications: 12VDC/24VDC:10A~15A 125VAC/250VAC:10A~16A
