UL Certified KSD301 250V10A 15A Thermal Switch 60℃ Normally Closed Bimetal Thermostat

Name: UL Certified KSD301 250V10A 15A Thermal Switch 60℃ Normally Closed Bimetal Thermostat
Brand: Nanjing Haichuan Electronic Co., Ltd.
SKU: KSD301/HC301
Availability: InStock

Brand Name:	HCET
Model Number:	KSD301/HC301
MOQ:	1000
Price:	please contact us
Delivery Time:	5-7 work days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

UL, TUV, CE

Document:

HC301.pdf

Product Name:

KSD301 Bimetal Thermal Switch

Material:

Ceramic Or Bakelite Body

Temperature Range:

-10~280℃

Tolerance:

±3℃,±5℃

Voltage:

250V AC

Current:

10A/16A

Application:

Juice Extractor Machine

Packaging Details:

2000 pcs per carton

Supply Ability:

10000000 pcs per month

Highlight:

UL Certified ksd301 250v10a

ksd301 250v10a Switch

ksd301 15a 250v Switch

Product Description

HCET KSD301 UL Certified Thermal Switch 250V 10A 60℃ Normally Closed Bimetal Thermostat for Juice Extractor Machine

The HCET KSD301 Bimetal Thermostat utilizes a precision calibrated bimetal to detect temperature changes. When the ambient temperature

reaches 60°C ± 5°C, the snap-action device immediately disconnects the 250V 10A circuit, providing overload protection for the motor,

compressor and heating elements. UL recognized construction ensures compliance with North American safety standards.

Compact design allows for seamless integration into space-constrained applications, from medical sterilizers to electric vehicle charging stations.

Product feature:

Industrial Grade Durability
Withstands 100,000+ cycles at 10A full load, ideal for continuous duty pumps and industrial ovens.
Medical Compliant
RoHS certified and safe for use in MRI machine cooling systems and dental autoclaves.
Intelligent reset function
Automatically restarts when the temperature reaches the reset temperature, eliminating the need for manual intervention of the thermal switch.
Global Voltage Coverage
250VAC rating is compatible with the 110-240V global grid and is certified for the US/California/EU markets.

Electrical Characteristics:

Temperature range:

-10℃~300℃

Temperature tolerance:

±3℃, ±5℃

Electrical specifications:

12VDC/24VDC:10A~15A

125VAC/250VAC:10A~16A

Product detail

UL Certified KSD301 250V10A 15A Thermal Switch 60℃ Normally Closed Bimetal Thermostat 0

Application

UL Certified KSD301 250V10A 15A Thermal Switch 60℃ Normally Closed Bimetal Thermostat 1
