Waterproof HCET Overcurrent Trip Switch Circuit Breaker For Air Compressor

Brand Name:	HCET
Model Number:	88
MOQ:	1000
Price:	please contact us
Delivery Time:	5-7 work days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

98 Thermal Overload Protector

Material:

Bakelite Case

Voltage:

125/250VAC 50VDC

Current:

3-25A

Reset Type:

Manual Reset

Application:

Air Compressor

Packaging Details:

500 pcs per carton

Supply Ability:

1000000 pcs per month

Highlight:

Waterproof overcurrent trip switch

Compressor overcurrent trip switch

Waterproof over current switch

Product Description

HCET WaterproofCircuit Breaker Thermal Overload Protector Overcurrent Protector for Air Compressor

HCET 88/98 series are mechatronic protection devices designed for air compressors and other high humidity and

strong vibration scenarios, utilizing bimetal mechanical drive: bimetal bending through the thermal effect of the current,

directly cutting off the circuit to protect the motor from overheating damage.

Product feature:

Moisture-proof sealing structure
Adopt silicone sealing ring + Bakelite shell, isolate water vapor, oil mist erosion, life expectancy increased by 3 times.
Overload protection
Bimetal responds to continuous overcurrent.
Short circuit protection
Electromagnetic disconnecting mechanism instantaneously cuts off short-circuit current (≥5 times rated current, response time <0.05 seconds).
Manual disconnection control
Top button operation

Electrical Characteristics:

*1000A125VAC 20A250VAC* Breaking Capacity	<60s Recovery Time
1500/min Insulation And Voltage Withstand Test	3A~25A Rated Current
<0.25V Minimum Voltage	*>500VDC100MΩ** Insulation Resistance

125/250VAC 50VDC 50~60HZ

Rated Voltage

Waterproof HCET Overcurrent Trip Switch Circuit Breaker For Air Compressor 0

Dimension size

Waterproof HCET Overcurrent Trip Switch Circuit Breaker For Air Compressor 1

Product detail

Waterproof HCET Overcurrent Trip Switch Circuit Breaker For Air Compressor 2

Application

Waterproof HCET Overcurrent Trip Switch Circuit Breaker For Air Compressor 3
